1200*1200 Sized With Customized Thickness Limestone Stone Honeycomb Panel
Product Description
Marble Stone Honeycomb Roof Panel at 1200 mm width and 1200 mm length with Customized Thickness is a stone honeycomb panel with a 1200 times 1200 mm size. The panel is especially for the roof use. With a good apperance and easy installation property, it is widely used for the building linkway roof cover. It is the most popular size for most of the projects are 1200mm times 1200 mm. As the panel weight is about 20 kg with which a regular man labor can easily handle but the size is large enough. For hanging one panel of this size, there will be four 600 * 600 mm2 sized panel hanged. It is a great saving of time and increases efficiency. Although the thickness can be customized, the weight and strength will not change too much. Many application field needing thicker panel can be realized.
The stone aluminum honeycomb panel generally uses a 3-5mm thickness stone veneer and 10-25mm thick aluminum honeycomb backing, which are to be bonded with a special adhesive. For the outdoor wall, it is recommended that the stone slide thickness be 4-5mm, aluminum honeycomb panel thickness not less than 25mm while for interior wall, stone thickness 3-4mm, aluminum honeycomb board thickness 15mm. For the ceiling, recommended thickness is 3-4mm and aluminum honeycomb panel thickness 15-20mm; for the floor, stone thickness 5-8mm, aluminum honeycomb panel thickness 10 -15mm.
Stone Description
Marble is a non-foliated metamorphic rock composed of recrystallized carbonate minerals, most commonly calcite or dolomite. Geologists use the term "marble" to refer to metamorphosed limestone; however, stonemasons use the term more broadly to encompass unmetamorphosed limestone. Marble is commonly used for sculpture and as a building material.
The advantages of the stone honeycomb panel:
1. Light weight
Because the marble veneer for stone honeycomb composite panel can be 3 ~ 5mm thick, and commonly used tiles or granite do need 12-15mm thickness. The weight of the composite stone honeycomb panel is only 1/6 of the weight of the traditional tile or granite, which can save considerable cost in terms of raw materials and transportation. Therefore, this is the best choice for use on buildings with load restrictions.
2. high strength
Stone Aluminum Honeycomb Sandwiched Panels with marble, the tiles, granite,and other composite, the bending and fracture resistance, shear strength were significantly improved, which greatly reduce the breaking rate during transportation, installation and use.
3.Improved anti-pollution ability
Regular original marble plate will change color or with dirty pollution on the surface if using the cement wet pasting. While for the composite panel, as the dense and hard substrate and the glue film, the above mentioned situation will not happen.
4. Easier to control color difference
The marble veneer used on the marble composite panels is three or four times more than the original plate. Therefore, the color and pattern can be 3 or 4 times more the same as the original marble plate.
5. Easy installation
Depending on the above characteristics, the efficiency and safety and costs of the installation process are greatly improved.
6. Break the restricted area
The original marble plate can be used on the inside and outside wall, ground, windowsill, porch, desktop, etc. But for the ceiling, no decoration company will take risk to use no matter it is marble or granite. The aluminum-plastic backed marble panels or aluminum honeycomb backed marble panel can break through the restricted area of stone honeycomb panel. Because it is very light that the weight of the whole body is only 1/5 to 1/10 of the original plate so that it is capable of being used on the ceiling.
7. Sound insulation and moisture-proof
An aluminum honeycomb backed stone panel transcends the properties of the original stone panel on the sound insulation, moisture and heat insulation and cold insulation performance because of the honeycomb structure.
8. Energy saving
Further to the above mentioned, Stone aluminum honeycomb panel, after installation in the indoor and outdoor, can greatly reduce the consumption of electricity and heat.
9. Cut costs
Due to thin and light stone composite material, it can save costs on transportation and installation. Furthermore, the finished composite stone panel will be more cost-efficient than their original plate.
Classical Marble Stone
| Marble Stone Type | Color | Location | Country |
| Carrara marble | white or blue-gray | Carrara, Tuscany | Italy |
| Connemara marble | green | Connemara, County Galway | Ireland |
| Creole marble | white and blue/black | Pickens County, Georgia | United States |
| Etowah marble | pink, salmon, rose | Pickens County, Georgia | United States |
| Murphy marble | white | Pickens and Gilmer Counties, Georgia | United States |
| Parian marble | pure-white, fine-grained | Island of Paros (Πάρος), South Aegean | Greece |
| Pentelic marble | pure-white, fine-grained semitranslucent | Mount Pentelicus, Attica | Greece |
| Purbeck marble | Gray/brown | Isle of Purbeck, Dorset | United Kingdom |
| Ruskeala marble | white | near Ruskeala, Karelia | Russia |
| Rușchița marble | white, pinkish, reddish | Poiana Ruscă Mountains, Caraș-Severin County | Romania |
| Sienna marble | yellow with violet, red, blue or white veins | near Siena, Tuscany | Italy |
| Bianco Sivec | white | near Prilep, Pelagonia | Macedonia |
| Swedish green marble | green | near Kolmården, Södermanland | Sweden |
| Sylacauga marble | white | Talladega County, Alabama | United States |
| Vermont marble | white | Proctor, Vermont | United States |
| Yule marble | uniform pure white | near Marble, Colorado | United States |
| Wunsiedel marble | white | Wunsiedel, Bavaria | Germany |
| Makrana marble | white | Makrana, Nagaur district, Rajasthan | India |
