Oxidation Resistance Metal Honeycomb Panels , Elevator Cab Interior Panels SS Material

Pasia Honeycomb Products Co., Ltd
Contact Now

Oxidation Resistance Metal Honeycomb Panels , Elevator Cab Interior Panels SS Material

  • 1
  • 2

Brand Name : Pasia

Model Number : SSHP25(2+22+1)

Certification : ISO9001-2008

Place of Origin : P. R. China

MOQ : 100 m2

Price : Negotiable

Supply Ability : 50,000 m2 per month

Delivery Time : within two weeks after order and down payment for MOQ quantity

Packaging Details : By Plywood crate or Pallet

Material : Stainless Steel

Thickness : 25mm

Surface Pattern : mill finished

Function : wall or floor panels for elevator or lifter

Edge : Folded

Product Name : Stainless Steel Honeycomb Panel

Contact Now

Stainless Steel Aluminum Honeycomb Panel for the Elevator or Lifter Wall or Floor Panels



Product Description



The Stainless Steel Aluminum Honeycomb Panel for the elevator or lifter wall or floor panels are with the regular stainless steel solid panel performance but with much lighter weight and flatter surfaces.



It possesses good properties as below:



Oxidation


High oxidation resistance in air at ambient temperature is normally achieved with additions of a minimum of 13% (by weight) chromium, and up to 26% is used for harsh environments. The chromium forms a passivation layer of chromium(III) oxide (Cr2O3) when exposed to oxygen. The layer is too thin to be visible, and the metal remains lustrous and smooth. The layer is impervious to water and air, protecting the metal beneath, and this layer quickly reforms when the surface is scratched. This phenomenon is called passivation and is seen in other metals, such as aluminium and titanium. Corrosion resistance can be adversely affected if the component is used in a non-oxygenated environment, a typical example being underwater keel bolts buried in timber.


When stainless steel parts such as nuts and bolts are forced together, the oxide layer can be scraped off, allowing the parts to weld together. When forcibly disassembled, the welded material may be torn and pitted, an effect known as galling. This destructive galling can be avoided by the use of dissimilar materials for the parts forced together, for example bronze and stainless steel, or even different types of stainless steels (martensitic against austenitic). However, two different alloys electrically connected in a humid environment may act as Voltaic pile and corrode faster. Nitronic alloys made by selective alloying with manganese and nitrogen may have a reduced tendency to gall. Additionally, threaded joints may be lubricated to prevent galling.


Acids



Stainless steel is generally highly resistant to attack from acids, but this quality depends on the kind and concentration of the acid, the surrounding temperature, and the type of steel. Type 904 is resistant to sulfuric acid at room temperature, even in high concentrations, type 316 and 317 are resistant below 10% and 304 should not be used at any concentration. All types of stainless steel resist attack from phosphoric acid, 316 and 317 more so than 304; and Types 304L and 430 have been successfully used with nitric acid. Hydrochloric acid will damage any kind of stainless steel, and should be avoided.





General Description



Stainless Steel Honeycomb Panel is comprised with two stainless steel plates and one aluminum or stainless steel honeycomb core layer. The upper surface can be colorful oxidation film coated or diamond anti-skidding pattern stainless steel plates. The colorful oxidation film performs well on corrosion resistance and cannot be peered off by mechanical friction.



In metallurgy, stainless steel, also known as inox steel or inox from French "inoxydable", is a steel alloy with a minimum of 10.5% chromium content by mass.


Stainless steel does not readily corrode, rust or stain with water as ordinary steel does. However, it is not fully stain-proof in low-oxygen, high-salinity, or poor air-circulation environments. There are different grades and surface finishes of stainless steel to suit the environment the alloy must endure. Stainless steel is used where both the properties of steel and corrosion resistance are required.



Stainless steel differs from carbon steel by the amount of chromium present. Unprotected carbon steel rusts readily when exposed to air and moisture. This iron oxide film (the rust) is active and accelerates corrosion by forming more iron oxide; and, because of the greater volume of the iron oxide, this tends to flake and fall away. Stainless steels contain sufficient chromium to form a passive film of chromium oxide, which prevents further surface corrosion by blocking oxygen diffusion to the steel surface and blocks corrosion from spreading into the metal's internal structure, and, due to the similar size of the steel and oxide ions, they bond very strongly and remain attached to the surface.





Characteristics:



No. Properties
1 Variety of colors for selection with various of pattern
2 Good corrosion resistance, greatly better than the stainless steel of the same type and the original color.
3 Heat Resistance, soaked in boiling water for 28 days or exposed at the 200 °C for long time, no change on the color and luster.
4 Abrasion resistance and good scratch performance, no color change after eraser friction more 2000 times at the pressure 500g/cm2.
5 film flexibility, after 180°T bend test and 8mm cupping test, film is without any change.
6 Scrubbing resistance, applicable on washing with any organic solvent, neutral detergent or water if there is dirt on the surface.
7 Anti-pollution performance, the surface can be restored by washing.
8 aging resistance better than regular stainless steel
9 possessing advantages of the honeycomb panel: 1) lower density and big flexural rigidity; 2) super flat surface; 3) good performance on sound absorption and insulation as well as thermal insulation
10 safe on fire resistance: A2 grade
11 environmental: recyclable





Application



Applicable on hotel, entertainment venues, high level exclusive shops, elevator panel, hall wall panel, carriage panel, backdrop, ceiling, decoration and signboard.
