Rock Wool Core Integrated Stone Honeycomb Sandwich Panel for Outdoor Cladding Use
Product Description
Rock Wool Integrated Stone Honeycomb Cladding is a stone veneer with honeycomb structure and backed with a rock wool panel for insulation purpose and installed on a lightweight steel keel system. This product can be completely manufactured in plant just leave the easy installation process on site. The surface veneers are diversified on paint, porcelain, stone, wood or bamboo veneers and so on. The building appearance can be customized based on specific project conditions and designer’s concept. It is easily moved and installed. Customization can be made according to the building conditions. The door and window openings can be reserved. The integrated honeycomb cladding is suitable for any building envelop. It can be connected with pillars by welding or bolts.
Spcification
The core panel thickness is about 120mm-300mm or customized according to the thermal and sound insulation requirements.
The size can be determined according to the real requirement with the maximum panel length 9 meters.
Mechanical Properties
| | ASTM | Unit | 10mm | 15mm | 20mm |
| Unit theory weight | | kg/m2 | 5.4 | 5.6 | 5.75 |
| Tensile strength | E8 | N/mm2 | 806 | 598 | 455 |
| Endurance capacity | E8 | N/mm2 | 531 | 405 | 279 |
| Elongation | E8 | % | 1.2 | 1.4 | 1.7 |
| Bending rigidity | C393 | X106N.mm2 | 8.03 | 15.4 | 38.44 |
| Bend elasticity rate | | N/mm2 | 50000 | 40600 | 38.44 |
| Temeprature total extension coefficient | D696 | X10-6N/℃ | 0.24 | 0.24 | 0.24 |
| Heat conduction rate | D976 | Kcal/mhr℃ | 0.23 | 0.19 | 0.15 |
| Heat transform temperature | D648 | ℃ | 200 | 200 | 200 |
| Bonding strength | C297 | | 12 | 12 | 12 |
| Surtace smoothness | 1mm/M.Maximum deviation:1mm/M |
| Flame retardabt property | Nonflammable,match relevant fire resistance standard |
| Soundproof function | Be decided by layout of printed sheet installation angle,0-3dB |
Feactures
It possesses advantages of:
1. Light weight
2. High strength
3. Increased anti-pollution ability
4. Easier control of uniform color
5. Easy installation
6. Workable at the area of regular stone not workable
7. Soundproof, moistureproof
8. Energy saving and consumption reduction
9. Reduce costs
Structure Combination
1) stone - aluminum honeycomb composite panels
2) stone - hard substrate composite panel
3) stone - tile composite panel
4) stone - stone composite panel
5) stone - glass composite panel known as stone translucent plate
2) by shape is divided into:
① general type plate
② arc plate
3) According to the surface:
① mirror panel
② matt panel
③ rough panel
Technical Options
| Thickness of Backing Panel | 8-50 mm |
| Panel Thickness (Standard) | 20 mm for indoor; 25 mm for outdoor (6mm stone surface + 19mm backing panel commonly used) or customized |
| Backing Panel Makeup (Interior curtain wall) | Both sides 0.7mm, 0.8mm mill Aluminum panel
|
| Stone | Mable / Granite / Limestone / Sandstone / Travetine,etc. |
| Finish | Polished / Honed / Flammed / Hammer Bush |
| Cell Size (Standard) | A6, 0.06mm |
| Adhesive | Aero Grade Epoxy Adhesive or PU glue |
| Anchoring Brackets | Aluminum or Stainless Steel |
| Application | Interior wall, floor, ceiling, counter top; Exterior wall, cladding, special parts etc; Shipbuilding, Train, Aircrafts |
| Certification | NOA for High Velocity Hurricane Zone/Warnock&Hersey |
| Feature | Lightweight / Large Area / High Impact Strength / Fast Installation / Cost decrease/Eco-friendly/Sound and thermal insulation |
| Maximum Dimension (mm) | 1500×3000 , or Subject to slab size |
